300NC Industrial Automatic Precision Cutting High Speed Circular Saw

Place of Origin : China

Brand Name : JSSCD

Model Number : JSSCD-300NC/P

MOQ : 1

Packaging Details : depending on the machine model

Delivery Time : 7-60 work days

Certification : HB24Q00435R0S HB24E0025 HB24S00242R0S8R0S

Dimension : 3000x3000x2500

Payment Terms : FOB

Color : Red，Black

Use : Material cutting

Saw type : Straight cut

Cuttable material : Carbon steel，Stainless steel，Alloy steel，Aluminum，Aluminum alloy，Copper，Copper alloy，Titanium alloy，PA

Safety protection devices : Emergency braking，Anti-splash shield

Condition : New

Mechanical control : Intelligent control，Automation

Feeding precision : ±0.1mm

Cutting precision : ±0.05mm

Name : JSSCD- 300NC/P CNC High Speed Circular Saw Machine

Application : Automobile manufacturing，Aerospace，Rail transit，Mechanical equipment，Hardware tools，Ship building，Building material，Pipeline engineering，Mold manufacturing，Electronics manufacturing

FAT : Sample trial cutting verification

Cutting debris removal device : Chain plate chip conveyer

Hydraulic oil : Reusable

Supply Ability : 500 Sets Per Year

Contact Now

JSSCD-300NC/P CNC High Speed Heavy Duty Circular Saw(Horizontal-Push)
This CNC high-speed circular saw machine is engineered for efficient and precise cutting of metal profiles, with exceptional performance in horizontal cutting operations. Combining high-speed cutting, automatic control, precision operation, and environmental performance, it has become an essential equipment in modern metal processing production lines.
Key Features
  • Precision cutting for various metal profiles including round pipes, angle steels, and square tubes
  • Optimized hydraulic horizontal/vertical clamping system reduces fixture changes
  • Intelligent control module for precise adjustment of cutting speed and angle
  • High-precision CNC control system with intuitive human-machine interface (HMI)
  • Supports fully automated production processes
Technical Specifications
Model Unit JSSCD-300NC/P
Mainframe dimensions mm 3000*3000*2500
Bar & round pipe mm 130-300
Angle bar & square bar mm 130-250
Saw blade size mm φ840*4.0*φ80
Pin holes and hole diameters mm 4*φ21*180 φ80
Spindle motor power KW 45(6P)
Spindle speed rpm 20-08
Feed servo motor power KW 7.5
Feeding servo motor power KW 5.5
Material removal length at the front end mm 20-99
Single feeding length(repeatable) mm 10-800
Hydraulic drive motor power KW 7.5
Rated pressure of the hydraulic system mpa 7.5
Hydraulic oil capacity L 150
Product Gallery
300NC Industrial Automatic Precision Cutting High Speed Circular Saw 300NC Industrial Automatic Precision Cutting High Speed Circular Saw 300NC Industrial Automatic Precision Cutting High Speed Circular Saw 300NC Industrial Automatic Precision Cutting High Speed Circular Saw
Frequently Asked Questions
Q1: Are you a manufacturer or a trading company?
We are a professional manufacturer of saw blade grinders. We have a 30,000 square meter factory and a team of dedicated technicians specializing in design, manufacturing, and sales.
Q2: Where is your factory located?
Our factory is located in Nantong City, Jiangsu Province, China. It takes about 1.5 hours from Shanghai Hongqiao station to our city.
Q3: What is your factory acceptance test method?
You can send us sample material to be cut, and we will perform a test cut using our machine. After the test is complete, we will provide you with detailed cutting data. (We will also send you a video of the machine cutting operation for your confirmation.)
Q4: What is your method of transaction?
We adopt the FOB (Free ON Board) transaction.
Q5: How about your delivery time?
Generally, it will take 7-60 work days after receiving your order. The specific delivery time depends on the items and the quantity of your order.
Q6: How about the payment term?
T/T 30% deposit, 70% of balance paid before shipment. (For other payment methods please contact our sales team)
Q7: Does the band saw blade have any international certifications?
Yes, we have obtained CE, ISO international certification.
